[![Build Status](https://travis-ci.org/clicon/clixon.png)](https://travis-ci.org/clicon/clixon) # Clixon Clixon is a YANG-based configuration manager, with interactive CLI, NETCONF and RESTCONF interfaces, an embedded database and transaction support. * [Background](#background) * [Frequently asked questions (FAQ)](doc/FAQ.md) * [Hello world](example/hello/README.md) * [Changelog](CHANGELOG.md) * [Installation](#installation) * [Licenses](#licenses) * [Support](#support) * [Dependencies](#dependencies) * [Extending](#extending) * [Yang](#yang) * [CLI](doc/CLI.md) * [XML and XPATH](#xml) * [Netconf](#netconf) * [Restconf](#restconf) * [Datastore](datastore/README.md) * [Authentication](#auth) * [NACM Access control](#nacm) * [Example](example/README.md) * [Runtime](#runtime) * [Clixon project page](http://www.clicon.org) * [Tests and CI](test/README.md) * [Scaling: large lists](doc/scaling/large-lists.md) * [Containers](docker/README.md) * [Roadmap](doc/ROADMAP.md) * [Reference manual](#reference) ## Background Clixon was implemented to provide an open-source generic configuration tool. The existing [CLIgen](http://www.cligen.se) tool was for command-lines only, while Clixon is a system with configuration database, xml and rest interfaces all defined by Yang. Most of the projects using Clixon are for embedded network and measuring devices. But Clixon can be used for other systems as well due to its modular and pluggable architecture. Users of Clixon currently include: * [Netgate](https://www.netgate.com) * [CloudMon360](http://cloudmon360.com) * [Grideye](http://hagsand.se/grideye) * [Netclean](https://www.netclean.com/solutions/whitebox) # only CLIgen * [Prosilient's PTAnalyzer](https://prosilient.com) # only CLIgen See also [Clicon project page](http://clicon.org). Clixon runs on Linux, [FreeBSD port](https://www.freshports.org/devel/clixon) and Mac/Apple. CPU architecures include x86_64, i686, ARM32. ## Installation A typical installation is as follows: ``` configure # Configure clixon to platform make # Compile sudo make install # Install libs, binaries, and config-files sudo make install-include # Install include files (for compiling) ``` One [example application](example/README.md) is provided, a IETF IP YANG datamodel with generated CLI, Netconf and restconf interface. ## Licenses Clixon is open-source and dual licensed. Either Apache License, Version 2.0 or GNU General Public License Version 2; you choose. See [LICENSE.md](LICENSE.md) for the license. ## Dependencies Clixon depends on the following software packages, which need to exist on the target machine. - [CLIgen](http://github.com/olofhagsand/cligen) If you need to build and install CLIgen: ``` git clone https://github.com/olofhagsand/cligen.git cd cligen; configure; make; make install ``` - Yacc/bison - Lex/Flex - Fcgi (if restconf is enabled) ## Support Clixon interaction is best done posting issues, pull requests, or joining the [slack channel](https://clixondev.slack.com). [Slack invite](https://join.slack.com/t/clixondev/shared_invite/enQtMzI3OTM4MzA3Nzk3LTA3NWM4OWYwYWMxZDhiYTNhNjRkNjQ1NWI1Zjk5M2JjMDk4MTUzMTljYTZiYmNhODkwMDI2ZTkyNWU3ZWMyN2U). ## Extending Clixon provides a core system and can be used as-is using available Yang specifications. However, an application very quickly needs to specialize functions. Clixon is extended by writing plugins for cli and backend. Extensions for netconf and restconf are also available. Plugins are written in C and easiest is to look at [example](example/README.md) or consulting the [FAQ](doc/FAQ.md). ## Yang YANG and XML is the heart of Clixon. Yang modules are used as a specification for handling XML configuration data. The YANG spec is used to generate an interactive CLI, netconf and restconf clients. It also manages an XML datastore. Clixon follows: - [YANG 1.0 RFC 6020](https://www.rfc-editor.org/rfc/rfc6020.txt) - [YANG 1.1 RFC 7950](https://www.rfc-editor.org/rfc/rfc7950.txt). - [RFC 7895: YANG module library](http://www.rfc-base.org/txt/rfc-7895.txt) However, the following YANG syntax modules are not implemented (reference to RFC7950 in parenthesis): - deviation (7.20.3) - action (7.15) - refine (7.13.2) - status (7.21.2) - extension (7.19) - YIN (13) - Yang extended Xpath functions: re-match(), deref)(), derived-from(), derived-from-or-self(), enum-value(), bit-is-set() (10.2-10.6) - Default values on leaf-lists are not supported (7.7.2) ### Yang patterns Yang type patterns use regexps defined in [W3C XML XSD](http://www.w3.org/TR/2004/REC-xmlschema-2-20041028). XSD regexp:s are slightly different from POSIX regexp. Clixon supports two regular expressions engines: * "Posix" which is the default method, which _translates_ XSD regexp:s to posix before matching with the standard Linux regex engine. This translation is not complete but can be considered "good-enough" for most yang use-cases. For reference, all standard Yang models in [https://github.com/YangModels/yang] have been tested. * "Libxml2" which uses the XSD regex engine in Libxml2. This is a complete XSD engine but you need to compile and link with libxml2 which may add overhead. To use libxml2 in clixon you need enable libxml2 in both cligen and clixon: ``` > ./configure --with-libxml2 # both cligen and clixon ``` You then need to set the following configure option: ``` libxml2 ``` ## XML Clixon has its own implementation of XML and XPATH implementation. The standards covered include: - [XML 1.0](https://www.w3.org/TR/2008/REC-xml-20081126) - [Namespaces in XML 1.0](https://www.w3.org/TR/2009/REC-xml-names-20091208) - [XPATH 1.0](https://www.w3.org/TR/xpath-10) Not supported: - !DOCTYPE (ie DTD) Historically, Clixon has not until 3.9 made strict namespace enforcing. For example, the following non-strict netconf was previously accepted: ``` ``` In 3.9, the same statement should be, for example: ``` ``` Note that base netconf syntax is still not enforced but recommended: ``` ``` ## Netconf Clixon implements the following NETCONF proposals or standards: - [RFC 6241: NETCONF Configuration Protocol](http://www.rfc-base.org/txt/rfc-6241.txt) - [RFC 6242: Using the NETCONF Configuration Protocol over Secure Shell (SSH)](http://www.rfc-base.org/txt/rfc-6242.txt) - [RFC 5277: NETCONF Event Notifications](http://www.rfc-base.org/txt/rfc-5277.txt) - [RFC 8341: Network Configuration Access Control Model](http://www.rfc-base.org/txt/rfc-8341.txt) The following RFC6241 capabilities/features are hardcoded in Clixon: - :candidate (RFC6241 8.3) - :validate (RFC6241 8.6) - :xpath (RFC6241 8.9) - :notification: (RFC5277) The following features are optional and can be enabled by setting CLICON_FEATURE: - :startup (RFC6241 8.7) Clixon does not support the following netconf features: - :url capability - copy-config source config - edit-config testopts - edit-config erropts - edit-config config-text - edit-config operation Some other deviations from the RFC: - edit-config xpath select statement does not support namespaces ## Restconf Clixon Restconf is a daemon based on FastCGI C-API. Instructions are available to run with NGINX. The implementatation is based on [RFC 8040: RESTCONF Protocol](https://tools.ietf.org/html/rfc8040). The following features are supported: - OPTIONS, HEAD, GET, POST, PUT, DELETE - stream notifications (RFC8040 sec 6) - query parameters start-time and stop-time(RFC8040 section 4.9) The following features are not implemented: - PATCH - query parameters other than start/stop-time. See [more detailed instructions](apps/restconf/README.md). ## Datastore The Clixon datastore is a stand-alone XML based datastore. The idea is to be able to use different datastores backends with the same API. Currently only an XML plain text datastore is supported. The datastore is primarily designed to be used by Clixon but can be used separately. See [more detailed instructions](datastore/README.md). ## Auth Authentication is managed outside Clixon using SSH, SSL, Oauth2, etc. For CLI, login is typically made via SSH. For netconf, SSH netconf subsystem can be used. Restconf however needs credentials. This is done by writing a credentials callback in a restconf plugin. See: * [FAQ](doc/FAQ.md#how-do-i-write-an-authentication-callback). * [Example](example/README.md) has an example how to do this with HTTP basic auth. * It has been done for other projects using Oauth2 or (https://github.com/CESNET/Netopeer2/tree/master/server/configuration) The clients send the ID of the user using a "username" attribute with the RPC calls to the backend. Note that the backend trusts the clients so the clients can in principle fake a username. ## NACM Clixon includes an experimental Network Configuration Access Control Model (NACM) according to [RFC8341(NACM)](https://tools.ietf.org/html/rfc8341). To enable NACM: * The `CLICON_NACM_MODE` config variable is by default `disabled`. * If the mode is internal`, NACM configurations are expected to be in the regular configuration, managed by regular candidate/runing/commit procedures. This mode may have some problems with bootstrapping. * If the mode is `external`, the `CLICON_NACM_FILE` yang config variable contains the name of a separate configuration file containing the NACM configurations. After changes in this file, the backend needs to be restarted. The [example](example/README.md) contains a http basic auth and a NACM backend callback for mandatory state variables. NACM is implemented in the backend with incoming RPC and data node access control points. The functionality is as follows (references to sections in [RFC8341](https://tools.ietf.org/html/rfc8341)): * Access control point support: * Incoming RPC Message validation is supported (3.4.4) * Data Node Access validation is supported (3.4.5), except: * rule-type data-node path is not supported * Outgoing noitification aithorization is _not_ supported (3.4.6) * RPC:s are supported _except_: * `copy-config`for other src/target combinations than running/startup (3.2.6) * `commit` - NACM is applied to candidate and running operations only (3.2.8) * Client-side RPC:s are _not_ supported. ## Runtime clixon sdk The figure shows the SDK runtime of Clixon. ## Reference Clixon uses [Doxygen](http://www.doxygen.nl/index.html) for reference documentation. You need to install doxygen and graphviz on your system. Build it in the doc directory and point the browser to `.../clixon/doc/html/index.html` as follows: ``` > cd doc > make doc > make graphs # detailed callgraphs ```
